All models of VERTICAL ANGULAR SLIDES sold by 4ManPro^® (For Manufacturing Processes) a Hann Huen Machinery & Hardware, Co., Ltd. BRANCH OFFICE are equipped with an indicator dial with crank for the transmission of motion in combination with a spindle or machining device.

It has a SLIDE PARALLEL TABLE to the sliding guides that allows the assembly of equipment on it to achieve a greater diversity of machining solutions.

The VAS (I) SERIES VERTICAL ANGULAR SLIDES models are made of stress-free wrought iron casting.

All VAS (I) SERIES elements feature a perpendicularity within 0.03 mm.

The VERTICAL ANGULAR SLIDES that makes up this section of elements is made up of the following devices:

ELEMENTS

VAS SERIES

• VAS-100
  • SLIDE STROKE:
    • 100.00 mm
  • LEAD SCREW TYPE:
    • Ø4 – 11
  • GRADUATED DIAL TYPE:
    • 2.0 x 0.01
  • SLIDING TABLE DIMENSIONS:
    • 100.00 mm x 150.00 mm

• VAS-150
  • SLIDE STROKE:
    • 150.00 mm
  • LEAD SCREW TYPE:
    • Ø4 – 13
  • GRADUATED DIAL TYPE:
    • 2.0 x 0.01
  • SLIDING TABLE DIMENSIONS:
    • 150.00 mm x 200.00 mm

• VAS-200
  • SLIDE STROKE:
    • 200.00 mm
  • LEAD SCREW TYPE:
    • Ø4 – 17.5
  • GRADUATED DIAL TYPE:
    • 2.0 x 0.01
  • SLIDING TABLE DIMENSIONS:
    • 200.00 mm x 250.00 mm

• VAS-250
  • SLIDE STROKE:
    • 250.00 mm
  • LEAD SCREW TYPE:
    • Ø4 – 17.5
  • GRADUATED DIAL TYPE:
    • 2.0 x 0.01
  • SLIDING TABLE DIMENSIONS:
    • 250.00 mm x 300.00 mm
