All models of VERTICAL PLATFORM SLIDERS marketed by 4ManPro^® (For Manufacturing Processes)una Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE, are equipped with indicator dial with crank for the transmission of motion in combination with a spindle or machining device.

It has a PLATFORM PERPENDICULAR to the sliding guides that allows the assembly of equipment on it to achieve a greater diversity of machining solutions.

The VAP SERIES VERTICAL PLATFORM SLIDING models are made of stress-free wrought iron casting.

All elements of the VAP SERIES have a perpendicularity within 0.03 mm.

The VERTICAL PLATFORM SLIDERS that make up this section of elements are made up of the following devices:

ELEMENTS

VAP SERIES

• VAP-100
  • SLIDE STROKE:
    • 100.00 mm.
  • LEAD SCREW TYPE:
    • Ø4 – 11
  • GRADUATED DIAL:
    • 2.0 x 0.01
  • PLATFORM DIMENSIONS:
    • 100.00 mm x 150.00 mm

• VAP-150
  • SLIDE STROKE:
    • 150.00 mm.
  • LEAD SCREW TYPE:
    • Ø4 – 13
  • GRADUATED DIAL:
    • 2.0 x 0.01
  • PLATFORM DIMENSIONS:
    • 200.00 mm x 200.00 mm

• VAP-200
  • SLIDE STROKE:
    • 200.00 mm.
  • LEAD SCREW TYPE:
    • Ø4 – 17
  • GRADUATED DIAL:
    • 2.0 x 0.01
  • PLATFORM DIMENSIONS:
    • 200.00 mm x 250.00 mm
