All models of VERTICAL TYPE HYDRAULIC SLIDERS sold by 4ManPro® (For Manufacturing Processes) una Hann Kuen Machinery & Hardware Co., Ltd. BRANCH OFFICE, are equipped with hydraulic cylinders for the transmission of motion in combination with a spindle or mechanized.
The VAH SERIES VERTICAL TYPE HYDRAULIC SLIDING models are equipped with rectangular, hardened and ground precision guides. This creates more friction and decreases speed, but greatly increases the durability and remanence of your accuracy.
All VAH SERIES elements have a perpendicularity within 0.01 mm / 100.00 mm.
These vertical slides can be used in combination with automatic hydraulic power units to ensure continuous work and repetitive results even in the longest type periods.
The VERTICAL TYPE HYDRAULIC SLIDERS that make up this section of elements are made up of the following devices:
Elements
VAH SERIES
- VAH220-300/420
- SLIDE STROKE:
- 100.00 mm
- SLIDE PISTON DIAMETER:
- Ø50 mm
- SLIDING TABLE DIMENSIONS:
- 220.00 mm x 300.00 mm
- SLIDE STROKE:
- VAH220-300/670
- SLIDE STROKE:
- 200.00 mm
- SLIDE PISTON DIAMETER:
- Ø50 mm
- SLIDING TABLE DIMENSIONS:
- 220.00 mm x 300.00 mm
- SLIDE STROKE:
- VAH300-360/540
- SLIDE STROKE:
- 120.00 mm
- SLIDE PISTON DIAMETER:
- Ø60 mm
- SLIDING TABLE DIMENSIONS:
- 300.00 mm x 300.00 mm
- SLIDE STROKE:
- VAH300-360/720
- SLIDE STROKE:
- 220.00 mm
- SLIDE PISTON DIAMETER:
- Ø60 mm
- SLIDING TABLE DIMENSIONS:
- 300.00 mm x 300.00 mm
- SLIDE STROKE:
- VAH360-360/920
- SLIDE STROKE:
- 250.00 mm
- SLIDE PISTON DIAMETER:
- Ø70 mm
- SLIDING TABLE DIMENSIONS:
- 360.00 mm x 300.00 mm
- SLIDE STROKE:
