All Servo Sliding models with Tempered Guides and Lead Screws Manufactured & Distributed by 4ManPro^® (For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH

OFFICE are equipped with Delta Electronics^® Brand Servo Motors, together providing us with a product with excellent quality and performance.

The BS SERIES LINEAR MOTION SERVO SLIDE models are equipped with rectangular, hardened and rectified precision guides. This generates more friction and decreases speed, but greatly increases the durability and remanence of its accuracy.

These slides are used when precision, cushioning and rigidity are required during machining. The surface of the rectangular guides and shims are ground and discarded, the contact surface of the saddle is coated with Turcite^®, which reduces friction.

The SERVO SLIDES included up this section of elements are made up of the following devices:

ELEMENTS

HS150 SERIES

HS150-200/300
- MAXIMUM SLIDE STROKE:
  - 80.00 mm
- SLIDE TABLE DIMENSIONS:
  - 150.00 mm x 200.00 mm

HS150-200/400
- MAXIMUM SLIDE STROKE:
  - 180.00 mm
- SLIDE TABLE DIMENSIONS:
  - 150.00 mm x 200.00 mm

HS180 SERIES

HS180-250/370
- MAXIMUM SLIDE STROKE:
  - 100.00 mm
- SLIDE TABLE DIMENSIONS:
  - 180.00 mm x 250.00 mm

HS180-250/470
- MAXIMUM SLIDE STROKE:
  - 200.00 mm
- SLIDE TABLE DIMENSIONS:
  - 180.00 mm x 250.00 mm

HS220 SERIES

HS220-300/420
- MAXIMUM SLIDE STROKE:
  - 100.00 mm
- BALL SCREW:
  - Ø16 – 6
- SLIDE TABLE DIMENSIONS:
  - 220.00 mm x 300.00 mm

HS220-300/520
- MAXIMUM SLIDE STROKE:
  - 200.00 mm
- BALL SCREW:
  - Ø16 – 8
- SLIDE TABLE DIMENSIONS:
  - 220.00 mm x 300.00 mm

HS220-300/670
- MAXIMUM SLIDE STROKE:
  - 350.00 mm
- BALL SCREW:
  - Ø16 – 10
- SLIDE TABLE DIMENSIONS:
  - 220.00 mm x 300.00 mm

HS220-420/670
- MAXIMUM SLIDE STROKE:
  - 230.00 mm
- BALL SCREW:
  - Ø16 – 10
- SLIDE TABLE DIMENSIONS:
  - 220 mm x 420.00 mm

HS220-420/800
- MAXIMUM SLIDE STROKE:
  - 360.00 mm
- BALL SCREW:
  - Ø16 – 12
- SLIDE TABLE DIMENSIONS:
  - 220.00 mm x 420.00 mm

HS220-420/940
- MAXIMUM SLIDE STROKE:
  - 500.00 mm
- BALL SCREW:
  - Ø16 – 12
- SLIDE TABLE DIMENSIONS:
  - 220.00 mm x 420.00 mm

HS250 SERIES

HS250-300/420
- MAXIMUM SLIDE STROKE:
  - 100.00 mm
- BALL SCREW:
  - Ø18 – 6
- SLIDE TABLE DIMENSIONS:
  - 250.00 mm x 300.00 mm

HS250-300/560
- MAXIMUM SLIDE STROKE:
  - 240.00 mm
- BALL SCREW:
  - Ø18 – 8
- SLIDE TABLE DIMENSIONS:
  - 250.00 mm x 300.00 mm

HS250-420/560
- MAXIMUM SLIDE STROKE:
  - 120.00 mm
- BALL SCREW:
  - Ø18 – 8
- SLIDE TABLE DIMENSIONS:
  - 250.00 mm x 420.00 mm

HS250-420/670
- MAXIMUM SLIDE STROKE:
  - 230.00 mm
- BALL SCREW:
  - Ø18 – 10
- SLIDE TABLE DIMENSIONS:
  - 250.00 mm x 420.00 mm

HS250-420/750
- MAXIMUM SLIDE STROKE:
  - 310.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 250.00 mm x 420.00 mm

HS250-420/940
- MAXIMUM SLIDE STROKE:
  - 500.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 250.00 mm x 420.00 mm

HS250-420/1200
- MAXIMUM SLIDE STROKE:
  - 760.00 mm
- BALL SCREW:
  - Ø18 – 14
- SLIDE TABLE DIMENSIONS:
  - 250.00 mm x 420.00 mm

HS300 SERIES

HS300-300/420
- MAXIMUM SLIDE STROKE:
  - 100.00 mm
- BALL SCREW:
  - Ø18 – 6
- SLIDE TABLE DIMENSIONS:
  - 300.00 mm x 300.00 mm

HS300-360/560
- MAXIMUM SLIDE STROKE:
  - 180.00 mm
- BALL SCREW:
  - Ø18 – 8
- SLIDE TABLE DIMENSIONS:
  - 300.00 mm x 360.00 mm

HS300-420/560
- MAXIMUM SLIDE STROKE:
  - 120.00 mm
- BALL SCREW:
  - Ø18 – 8
- SLIDE TABLE DIMENSIONS:
  - 300.00 mm x 420.00 mm

HS300-420/670
- MAXIMUM SLIDE STROKE:
  - 230.00 mm
- BALL SCREW:
  - Ø18 – 10
- SLIDE TABLE DIMENSIONS:
  - 300.00 mm x 420.00 mm

HS300-420/800
- MAXIMUM SLIDE STROKE:
  - 360.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 300.00 mm x 420.00 mm

HS300-420/940
- MAXIMUM SLIDE STROKE:
  - 500.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 300.00 mm x 420.00 mm

HS300-420/1200
- MAXIMUM SLIDE STROKE:
  - 760.00 mm
- BALL CREW:
  - Ø18 – 14
- SLIDE TABLE DIMENSIONS:
  - 300.00 mm x 420.00 mm

HS360 SERIES

HS360-360/560
- MAXIMUM SLIDE STROKE:
  - 180.00 mm
- BALL SCREW:
  - Ø18 – 8
- SLIDE TABLE DIMENSIONS:
  - 360.00 mm x 360.00 mm

HS360-420/560
- MAXIMUM SLIDE STROKE:
  - 120.00 mm
- BALL SCREW:
  - Ø18 – 8
- SLIDE TABLE DIMENSIONS:
  - 360.00 mm x 420.00 mm

HS360-420/670
- MAXIMUM SLIDE STROKE:
  - 230.00 mm
- BALL SCREW:
  - Ø18 – 10
- SLIDE TABLE DIMENSIONS:
  - 360.00 mm x 420.00 mm

HS360-420/800
- MAXIMUM SLIDE STROKE:
  - 360.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 360.00 mm x 420.00 mm

HS360-520/800
- MAXIMUM SLIDE STROKE:
  - 260.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 360.00 mm x 520.00 mm

HS360-520/940
- MAXIMUM SLIDE STROKE:
  - 400.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 360.00 mm x 520.00 mm

HS360-600/1200
- MAXIMUM SLIDE STROKE:
  - 580.00 mm
- BALL SCREW:
  - Ø18 – 14
- SLIDE TABLE DIMENSIONS:
  - 360.00 mm x 600.00 mm

HS420 SERIES

HS420-420/560
- MAXIMUM SLIDE STROKE:
  - 120.00 mm
- BALL SCREW:
  - Ø18 – 8
- SLIDE TABLE DIMENSIONS:
  - 420.00 mm x 420.00 mm

HS420-420/670
- MAXIMUM SLIDE STROKE:
  - 230.00 mm
- BALL SCREW:
  - Ø18 – 10
- SLIDE TABLE DIMENSIONS:
  - 420.00 mm x 420.00 mm

HS420-520/940
- MAXIMUM SLIDE STROKE:
  - 400.00 mm
- BALL SCREW:
  - Ø18 – 12
- SLIDE TABLE DIMENSIONS:
  - 420.00 mm x 520.00 mm

HS420-600/1200
- MAXIMUM SLIDE STROKE:
  - 580.00 mm
- BALL SCREW:
  - Ø18 – 14
- SLIDE TABLE DIMENSIONS:
  - 420.00 mm x 600.00 mm

HS500 SERIES

HS500-520/885
- MAXIMUM SLIDE STROKE:
  - 345.00 mm
- BALL SCREW:
  - Ø22 – 10
- SLIDE TABLE DIMENSIONS:
  - 500.00 mm x 520.00 mm

HS500-600/1200
- MAXIMUM SLIDE STROKE:
  - 580.00 mm
- BALL SCREW:
  - Ø22 – 12
- SLIDE TABLE DIMENSIONS:
  - 500.00 mm x 600.00 mm

HS500-600/1800
- MAXIMUM SLIDE STROKE:
  - 1,180.00 mm
- BALL SCREW:
  - Ø22 – 12
- SLIDE TABLE DIMENSIONS:
  - 500.00 mm x 600.00 mm

HS600 SERIES

HS600-520/885
- MAXIMUM SLIDE STROKE:
  - 345.00 mm
- BALL SCREW:
  - Ø22 – 10
- SLIDE TABLE DIMENSIONS:
  - 600.00 mm x 520.00 mm

HS600-600/1200
- MAXIMUM SLIDE STROKE:
  - 580.00 mm
- BALL SCREW:
  - Ø22 – 12
- SLIDE TABLE DIMENSIONS:
  - 600.00 mm x 600.00 mm

HS600-600/1800
- MAXIMUM SLIDE STROKE:
  - 1,180.00 mm
- BALL SCREW:
  - Ø22 – 12
- SLIDE TABLE DIMENSIONS:
  - 600.00 mm x 600.00 mm
