All models of Servo Slides with Hardened Guides and Ball Screw marketed by 4ManPro® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE are equipped with Delta Electronics® brand servomotors, providing a product with excellent quality and performance.
The BS Series Linear Motion Servo Slides are equipped with hardened and ground rectangular precision guides. This generates more friction and reduces speed, but greatly increases durability and accuracy retention.
These slides are used when precision, damping, and rigidity are required during machining. The surface of the rectangular guides and wedges is ground and removed, and the saddle contact surface is coated with Turcite®, which reduces friction.
The Servo Slides included in this section consist of the following components:
ELEMENTOS
BS-150
- BS150-200/300
- Carrera:
- 100.00 mm
- Mesa:
- 180.00 mm x 250.00 mm
- Carrera:
- BS150-200/400
- Carrera:
- 200.00 mm
- Mesa:
- 180.00 mm x 250.00 mm
- Carrera:
BS-180
- BS180-250/370
- Carrera:
- 100.00 mm
- Mesa:
- 180.00 mm x 250.00 mm
- Carrera:
- BS180-250/470
- Carrera:
- 200.00 mm
- Mesa:
- 180.00 mm x 250.00 mm
- Carrera:
BS-220
- BS220-300/420
- Carrera: 100.00 mm
- Tornillo: Ø16 – 6
- Mesa: 220.00 mm x 300.00 mm
- BS220-300/520
- Carrera: 200.00 mm
- Tornillo: Ø16 – 8
- Mesa: 220.00 mm x 300.00 mm
- BS220-300/670
- Carrera: 350.00 mm
- Tornillo: Ø16 – 10
- Mesa: 220.00 mm x 300.00 mm
- BS220-420/670
- Carrera: 230.00 mm
- Tornillo: Ø16 – 10
- Mesa: 220.00 mm x 420.00 mm
- BS220-420/800
- Carrera: 360.00 mm
- Tornillo: Ø16 – 12
- Mesa: 220.00 mm x 420.00 mm
- BS220-420/940
- Carrera: 500.00 mm
- Tornillo: Ø16 – 12
- Mesa: 220.00 mm x 420.00 mm
BS-250
- BS250-300/420
- Carrera: 100.00 mm
- Tornillo: Ø18 – 6
- Mesa: 250.00 mm x 300.00 mm
- BS250-300/560
- Carrera: 240.00 mm
- Tornillo: Ø18 – 8
- Mesa: 250.00 mm x 300.00 mm
- BS250-420/560
- Carrera: 120.00 mm
- Tornillo: Ø18 – 8
- Mesa: 250.00 mm x 420.00 mm
- BS250-420/670
- Carrera: 230.00 mm
- Tornillo: Ø18 – 10
- Mesa: 250.00 mm x 420.00 mm
- BS250-420/750
- Carrera: 310.00 mm
- Tornillo: Ø18 – 12
- Mesa: 250.00 mm x 420.00 mm
- BS250-420/940
- Carrera: 500.00 mm
- Tornillo: Ø18 – 12
- Mesa: 250.00 mm x 420.00 mm
- BS250-420/1200
- Carrera: 760.00 mm
- Tornillo: Ø18 – 14
- Mesa: 250.00 mm x 420.00 mm
BS-300
- BS300-300/420
- Carrera: 100.00 mm
- Tornillo: Ø18 – 6
- Mesa: 300.00 mm x 300.00 mm
- BS300-360/560
- Carrera: 180.00 mm
- Tornillo: Ø18 – 8
- Mesa: 300.00 mm x 360.00 mm
- BS300-420/560
- Carrera: 120.00 mm
- Tornillo: Ø18 – 8
- Mesa: 300.00 mm x 420.00 mm
- BS300-420/670
- Carrera: 230.00 mm
- Tornillo: Ø18 – 10
- Mesa: 300.00 mm x 420.00 mm
- BS300-420/800
- Carrera: 360.00 mm
- Tornillo: Ø18 – 12
- Mesa: 300.00 mm x 420.00 mm
- BS300-420/940
- Carrera: 500.00 mm
- Tornillo: Ø18 – 12
- Mesa: 300.00 mm x 420.00 mm
- BS300-420/1200
- Carrera: 760.00 mm
- Tornillo: Ø18 – 14
- Mesa: 300.00 mm x 420.00 mm
BS-360
- BS360-360/560
- Carrera: 180.00 mm
- Tornillo: Ø18 – 8
- Mesa: 360.00 mm x 360.00 mm
- BS360-420/560
- Carrera: 120.00 mm
- Tornillo: Ø18 – 8
- Mesa: 360.00 mm x 420.00 mm
- BS360-420/670
- Carrera: 230.00 mm
- Tornillo: Ø18 – 10
- Mesa: 360.00 mm x 420.00 mm
- BS360-420/800
- Carrera: 360.00 mm
- Tornillo: Ø18 – 12
- Mesa: 360.00 mm x 420.00 mm
- BS360-520/800
- Carrera: 260.00 mm
- Tornillo: Ø18 – 12
- Mesa: 360.00 mm x 520.00 mm
- BS360-520/940
- Carrera: 400.00 mm
- Tornillo: Ø18 – 12
- Mesa: 360.00 mm x 520.00 mm
- BS360-600/1200
- Carrera: 580.00 mm
- Tornillo: Ø18 – 14
- Mesa: 360.00 mm x 600.00 mm
BS-420
- BS420-420/560
- Carrera: 120.00 mm
- Tornillo: Ø18 – 8
- Mesa: 420.00 mm x 420.00 mm
- BS420-420/670
- Carrera: 230.00 mm
- Tornillo: Ø18 – 10
- Mesa: 420.00 mm x 420.00 mm
- BS420-520/940
- Carrera: 400.00 mm
- Tornillo: Ø18 – 12
- Mesa: 420.00 mm x 520.00 mm
- BS420-600/1200
- Carrera: 580.00 mm
- Tornillo: Ø18 – 14
- Mesa: 420.00 mm x 600.00 mm
BS-500
- BS500-520/885
- Carrera: 345.00 mm
- Tornillo: Ø22 – 10
- Mesa: 500.00 mm x 520.00 mm
- BS500-600/1200
- Carrera: 580.00 mm
- Tornillo: Ø22 – 12
- Mesa: 500.00 mm x 600.00 mm
- BS500-600/1800
- Carrera: 1,180.00 mm
- Tornillo: Ø22 – 12
- Mesa: 500.00 mm x 600.00 mm
BS-600
- BS600-520/885
- Carrera: 345.00 mm
- Tornillo: Ø22 – 10
- Mesa: 600.00 mm x 520.00 mm
- BS600-600/1200
- Carrera: 580.00 mm
- Tornillo: Ø22 – 12
- Mesa: 600.00 mm x 600.00 mm
- BS600-600/1800
- Carrera: 1,180.00 mm
- Tornillo: Ø22 – 12
- Mesa: 600.00 mm x 600.00 mm
