At 4ManPro® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE, we have the widest line of line heads for the most common applications within the industry.
Likewise, we also have the development of heads manufactured according to customer specifications for specialized applications and very demanding production levels, being fixed-type elements to meet the specific specifications of each project.
Within these product lines we have the A SERIES of MULTIPLE HEADS for DRILLING or TAPPING applications, where between 2 and 4 SPINDLE POINTS are required. Below we present the elements that make up this series.
ELEMENTS
- A-100 (A-116) MODEL
- NOZZLE TYPE:
- C-6
- MAXIMUM DISTANCE BETWEEN CENTERS:
- 100.00 mm.
- DISTANCIA MÍNIMA ENTRE CENTRO:
- 18.00 mm.
- RATIO TRANSMISSION:
- 1 : 1
- MAXIMUM DRILLING CAPACITY:
- Ø6 mm.
- MAXIMUM TAPPING CAPACITY:
- M-6.
- NUMBER OF SPINDLE TIPS:
- 2 ~ 4
- NOZZLE TYPE:
- A-124 MODEL
- NOZZLE TYPE:
- C-9
- MAXIMUM DISTANCE BETWEEN CENTERS:
- 124.00 mm.
- MINIMUM DISTANCE BETWEEN CENTERS:
- 26.00 mm.
- RATIO TRANSMISSION:
- 1 : 1
- MAXIMUM DRILLING CAPACITY:
- Ø9 mm.
- MAXIMUM TAPPING CAPACITY:
- M-8.
- NUMBER OF SPINDLE TIPS:
- 2 ~ 4
- NOZZLE TYPE:
- A-124S MODEL
- NOZZLE TYPE:
- C-9
- MAXIMUM DISTANCE BETWEEN CENTERS:
- 124.00 mm.
- MINIMUM DISTANCE BETWEEN CENTERS:
- 26.00 mm.
- RATIO TRANSMISSION:
- 1 : 1
- MAXIMUM DRILLING CAPACITY:
- Ø9 mm.
- MAXIMUM TAPPING CAPACITY:
- M-8.
- NUMBER OF SPINDLE TIPS:
- 2 ~ 4
- NOZZLE TYPE:
