Another essential component of 4ManPro^® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware Co., Ltd. BRANCH OFFICE, are the SSD SERIES SERVO HEADS.

These Heads are highly relevant for the processes of Milling, Boring, Tapping, Drilling, etc…, with high Reliability and Precision for the most demanding work environments.

The SSD SERIES is made up of the following models of Servo Heads.

ELEMENTS

SSD SERIES

• SSD03-60
  • Maximum Spindle Speed: 10,000 r.p.m.
  • Maximum Spindle Stroke: 60.00 mm.
  • Maximum Drilling Capacity: Ø6mm

• SSD03-80
  • Maximum Spindle Speed: 10,000 r.p.m.
  • Maximum Spindle Stroke: 80.00 mm.
  • Maximum Drilling Capacity: Ø6mm

• SSD05-85
  • Maximum Spindle Speed: 5,000 r.p.m.
  • Maximum Spindle Stroke: 85.00 mm.
  • Maximum Drilling Capacity: Ø13mm

• SSD06-100
  • Maximum Spindle Speed: 3,500 r.p.m.
  • Maximum Spindle Stroke: 100.00 mm.
  • Maximum Drilling Capacity: Ø16mm

• SSD06H-100
  • Maximum Spindle Speed: 10,000 r.p.m.
  • Maximum Spindle Stroke: 100.00 mm.
  • Maximum Drilling Capacity: Ø16mm

• SSD09-120
  • Maximum Spindle Speed: 3,000 r.p.m.
  • Maximum Spindle Stroke: 120.00 mm.
  • Maximum Drilling Capacity: Ø25mm

• SSD09H-120
  • Maximum Spindle Speed: 8,000 r.p.m.
  • Maximum Spindle Stroke: 120.00 mm.
  • Capacidad Máxima De Perforado:Ø25mm.

• SSD12-150
  • Maximum Spindle Speed: 2,000 r.p.m.
  • Maximum Spindle Stroke: 150.00 mm.
  • Maximum Drilling Capacity: Ø35mm

• SSD12H-150
  • Maximum Spindle Speed: 6,000 r.p.m.
  • Maximum Spindle Stroke: 150.00 mm.
  • Maximum Drilling Capacity: Ø35mm

• SSD15-150
  • Maximum Spindle Speed: 1,600 r.p.m.
  • Maximum Spindle Stroke: 150.00 mm.
  • Maximum Drilling Capacity: Ø50mm

• SSD15H-150
  • Maximum Spindle Speed: 4,000 r.p.m.
  • Maximum Spindle Stroke: 150.00 mm.
  • Maximum Drilling Capacity: Ø50mm
