SD (03-08) SERIES

4ManPro® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE stands out as a leader in the manufacture of HIGH PRECISION DRILLING HEADS, playing a crucial role in the advanced manufacturing industry. Renowned for their innovative design and mechanical robustness, 4ManPro® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE DRILLING HEADS are the result of decades of meticulous engineering and an unwavering commitment to excellence.

Each head is constructed from the highest quality materials, specifically selected to resist wear and extend the life of the equipment. Its key components are subjected to rigorous heat treatment processes and special coatings to maximize their durability and corrosion resistance.

The exceptional performance of these heads is due to the integration of cutting-edge technologies, including micron-precision control systems and efficient drive mechanisms that minimize vibration and operating noise. Furthermore, the modular design of the heads allows for easy adaptability and customization according to specific customer needs, ensuring optimal compatibility with various industrial applications.

4ManPro® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE reputation for superior quality is confirmed through strict quality controls and international certifications, ensuring that each product meets and exceeds most demanding standards in the industry.

In summary, 4ManPro® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE represent the perfect combination of performance and reliability, positioning themselves as the preferred choice for applications requiring precision and resistance without compromising operational efficiency.

The ELEMENTS that make up the SD SERIES (03-08) are listed below:

ELEMENTS

SD03 SERIES

SD03-60M
- MAXIMUM SPINDLE STROKE:
  - 60.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø6 mm
- MAXIMUM SPINDLE SPEED:
  - 10,000 r.p.m.
- MOVEMENT TYPE:
  - HYDRAULIC

SD03-80M
- MAXIMUM SPINDLE STROKE:
  - 80.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø6 mm
- MAXIMUM SPINDLE SPEED:
  - 10,000 r.p.m.
- MOVEMENT TYPE:
  - HYDRAULIC

SD03A-55M
- MAXIMUM SPINDLE STROKE:
  - 55.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø6 mm
- MAXIMUM SPINDLE SPEED:
  - 10,000 r.p.m.
- MOVEMENT TYPE:
  - PNEUMATIC

SD03A-75M
- MAXIMUM SPINDLE STROKE:
  - 75.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø6 mm
- MAXIMUM SPINDLE SPEED:
  - 10,000 r.p.m.
- MOVEMENT TYPE:
  - PNEUMATIC

SD05 SERIES

SD5-85M
- MAXIMUM SPINDLE STROKE:
  - 85.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø13 mm
- MAXIMUM SPINDLE SPEED:
  - 5,000 r.p.m.
- MOVEMENT TYPE:
  - HYDRAULIC

SD05A-85
- MAXIMUM SPINDLE STROKE:
  - 85.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø13 mm
- MAXIMUM SPINDLE SPEED:
  - 5,000 r.p.m.
- MOVEMENT TYPE:
  - PNEUMATIC

SD07 SERIES

SD07-130M
- MAXIMUM SPINDLE STROKE:
  - 130.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø20 mm
- MAXIMUM SPINDLE SPEED:
  - 2,500 r.p.m.
- MOVEMENT TYPE:
  - HYDRAULIC

SD08 SERIES

SD08-150M
- MAXIMUM SPINDLE STROKE:
  - 150.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø35 mm
- MAXIMUM SPINDLE SPEED:
  - 1,500 r.p.m.
- MOVEMENT TYPE:
  - HYDRAULIC

SD08-200M
- MAXIMUM SPINDLE STROKE:
  - 200.00 mm
- MAXIMUM DRILLING CAPACITY:
  - Ø35 mm
- MAXIMUM SPINDLE SPEED:
  - 1,500 r.p.m.
- MOVEMENT TYPE:
  - HYDRAULIC
