A complement to CONTINUOUS WORK LUBRICATION SYSTEMS or HIGH PERFORMANCE SYSTEMS are FORCED CYCLE LUBRICATION SYSTEMS. By providing a high lubrication flow to the process, the performance of the machining systems is substantially increased, as well as the life of the tooling, thus obtaining excellent cost/performance with your application.
FORCED CYCLE LUBRICATION SYSTEMS can be used in combination with the elements of the ISH YLB SERIES, ISH YLS SERIES and ISH YLD SERIES.
The operation of these Lubrication Systems can be summarized as follows:
- The pressure switch is to detect the pressure value in the pipeline to ensure the operation of the machine.
- The float switch is designed to give signal and alarm when the lubricant is insufficient.
- Pressure regulating valve attached to adjust the pressure value in the pipeline.
- The filter is equipped to filter impurities and iron filings to ensure the cleanliness of the lubricant.
- The lubricant can be circulated to reduce its consumption.
- The radiator is designed to cool the lubricant and prolong.
- lubrication performance. (ISH YLD SERIES ONLY).
The elements included in this variant are grouped in the following series:
FORCED CYCLE LUBRICATING SYSTEMS
- OIL PUMP POWER:
- ½ H.P.
- SYSTEM MAXIMUM PRESSURE:
- 0.50 MPa / 5.00 Kgf/cm²
- LUBRICANT DEPOSIT CAPACITY (Liters):
- 20/30/40/60/80
- OIL PUMP POWER:
- ½ H.P.
- SYSTEM MAXIMUM PRESSURE:
- 1.50 MPa (15.00 Kgf/cm²)
- LUBRICANT DEPOSIT CAPACITY (Liters):
- 30/40/60/80/100
- OIL PUMP POWER:
- ¼ H.P.
- SYSTEM MAXIMUM PRESSURE:
- 0.50 MPa / 5.00 Kgf/cm²
- LUBRICANT DEPOSIT CAPACITY (Liters):
- 30/40
