The Bodies of the Spindle Heads and Spindles for Milling and Boring with Round Housing Spindle Case, distributed by 4ManPro® (Elements For Manufacturing Processes) a Hann Kuen Machinery & Hardware Co., Ltd. BRANCH OFFICE, are made of FC30 cast iron, which after being subjected to an exhaustive review, are processed by Drilling and Honing. precission. All our spindles are manufactured from alloy steels subjected to high-frequency heat treatment.
The SRR SERIES Milling and Boring Spindle Heads and Spindles have round-shaped bodies and open housing to provide greater performance for Heavy Duty and High Speed applications in continuous working conditions. Likewise, its open style body adapts in a simpler and more transparent way to the most complex designs for high-performance automated manufacturing stations.
These spindles are assembled with precision bearings SKF® (Germany), NSK® (Japan) and TPI® (Taiwan) that maintain the precision of the spindle tip at < 0.02 mm.
Its maximum speed is suitable for mounting on a BS SERIES or HS SERIS CNC Servo Slide, or a hydraulic feed table for your machining applications.
The elements that make up the SRR SERIES are described below:
Elements
SRR SERIES
OPEN HOUSING HIGH PERFORMANCE SPINDLES STANDARDS TYPE
SRR-H SERIES
OPEN HOUSING HIGH PERFORMANCE SPINDLES HIGH SPEED TYPE
- SRR-35H
- Spindle Type: NT-30
- Maximum Spindle Speed: 3,000 r.p.m.
- Maximum Spindle Power: 2 H.P.
- SRR-45H
- Spindle Type: NT-40
- Maximum Spindle Speed: 2,000 r.p.m.
- Maximum Spindle Power: 3 H.P.
- SRR-55H
- Spindle Type: NT-40
- Maximum Spindle Speed: 2,000 r.p.m.
- Maximum Spindle Power: 3 H.P.
- SRR-60H
- Spindle Type: NT-40
- Maximum Spindle Speed: 1,800 r.p.m.
- Maximum Spindle Power: 5 H.P.
- SRR-75H
- Spindle Type: NT-50
- Maximum Spindle Speed: 1,600 r.p.m.
- Maximum Spindle Power: 5 H.P.
- SRR-80H
- Spindle Type: NT-50/A25
- Maximum Spindle Speed: 1,200 r.p.m.
- Maximum Spindle Power: 7.5 H.P.
