The Head and Spindle Bodies distributed by 4ManPro^® (For Manufacturing Processes) a Hann Kuen Machinery & Hardware, Co., Ltd. BRANCH OFFICE, are made of FC30 cast iron, which after being subjected to an exhaustive review, are processed by precision drilling and burnishing. The spindles are manufactured from alloy steels subjected to high-frequency heat treatment.

Están ensamblados con rodamientos de precisión SKF^® (Alemania), NSK^® (Japón) y TPI^® (Taiwán) que mantienen la precisión de la punta del husillo en < 0.02 mm.

They are assembled with SKF^® (Germany), NSK^® (Japan) and TPI^® (Taiwan) precision bearings that maintain spindle tip precision at < 0.02 mm.

Its maximum speed is suitable for mounting on a CNC Servo Slide or hydraulic feed table for your machining applications.

The elements that make up the S SERIES are described below:

ELEMENTS

S SERIES

STANDARD SPEED DEVICES

• S25
  • Spindle Type: ER32
  • Maximum Spindle Speed: 4,000 r.p.m.
  • Potencia Máxima: ½ H.P.
• S35
  • Spindle Type: ER32
  • Maximum Spindle Speed: 3,000 r.p.m.
  • Potencia Máxima: 1 H.P.
• S45
  • Spindle Type: ER40
  • Maximum Spindle Speed: 3,000 r.p.m.
  • Potencia Máxima: 2 H.P.
• S55
  • Spindle Type: ER40
  • Maximum Spindle Speed: 2,000 r.p.m.
  • Potencia Máxima: 3 H.P.
• S60
  • Spindle Type: NT40
  • Maximum Spindle Speed: 1,800 r.p.m.
  • Potencia Máxima: 5 H.P.
• S75
  • Spindle Type: NT50
  • Maximum Spindle Speed: 1,600 r.p.m.
  • Potencia Máxima: 5 H.P.
• S80
  • Spindle Type: NT50
  • Maximum Spindle Speed: 1,200 r.p.m.
  • Potencia Máxima: 7.5 H.P.

• S100
  • Spindle Type: NT50/A₂-6
  • Maximum Spindle Speed: 800 r.p.m.
  • Potencia Máxima: 15 H.P.
• S120
  • Spindle Type: NT50/A₂-6
  • Maximum Spindle Speed: 600 r.p.m.
  • Maximum Spindle Power: 20 H.P.
• S150 NEW!
  • Spindle Type: NT50
  • Maximum Spindle Speed: 500 r.p.m.
  • Potencia Máxima: 20 H.P.

S-H SERIES

HIGH PERFORMANCE DEVICES

• S25H
  • Spindle Type: ER32
  • Maximum Spindle Speed: 12,000 r.p.m.
  • Potencia Máxima: ½ H.P.
• S35H
  • Spindle Type: ER32
  • Maximum Spindle Speed: 10,000 r.p.m.
  • Potencia Máxima: 1 H.P.
• S45H
  • Spindle Type: ER40
  • Maximum Spindle Speed: 8,000 r.p.m.
  • Potencia Máxima: 2 H.P.
• S55H
  • Spindle Type: ER40
  • Maximum Spindle Speed: 6,000 r.p.m.
  • Potencia Máxima: 3 H.P.
• S60H
  • Spindle Type: NT40
  • Maximum Spindle Speed: 5,000 r.p.m.
  • Potencia Máxima: 5 H.P
• S75H
  • Spindle Type: NT50
  • Maximum Spindle Speed: 4,000 r.p.m.
  • Potencia Máxima: 5 H.P.
• S80H
  • Spindle Type: NT50
  • Maximum Spindle Speed: 3,000 r.p.m.
  • Potencia Máxima: 7.55 H.P.

• S100H
  • Spindle Type: NT50/A₂-6
  • Maximum Spindle Speed: 2,500 r.p.m.
  • Potencia Máxima: 15 H.P.
• S120H
  • Spindle Type: NT50/A₂-6
  • Maximum Spindle Speed: 2,000 r.p.m.
  • Potencia Máxima: 20 H.P.
• S150H NEW!
  • Spindle Type: NT50
  • Maximum Spindle Speed: 1,800 r.p.m.
  • Potencia Máxima: 20 H.P.
