HYDRAULIC ELEMENTS CHARACTERISTICS
- Diameter : Ø25.00 mm ~ Ø40.00 mm.
- Pmax : 140.00 Kg/cm²
- In this type of hydraulic cylinder, the clamping mechanism is the lever principle, the piston is pushed out in a clamping state, the clamping force is greater than that of the corner cylinder, and the main parts of the mechanism are installed outside the cylinder body, which is easy to maintain.
- The cylinder barrel and clamping mechanism are made of structural carbon steel for maximum durability and long service life.
- Clamping arm: S45C material hardness HRC26˚~30˚.
HYDRAULIC CAM CLAMPING CYLINDER
- HLB-25
- HLB-32
- HLB-40
** PDF DOWNLOAD – HLB SERIES
MANIFOLD LEVER TYPE HYDRAULIC CLAMPING CYLINDER
- HLB-M 25
- HLB-M 32
- HLB-M 40
** PDF DOWNLOAD – HLB-M SERIES
HYDRAULIC LEVER CLAMPING CYLINDER WITH MANIFOLD AND FLOW CONTROL
- HLB-MF 25
- HLB-MF 32
- HLB-MF 40
** PDF DOWNLOAD – HLB-MF SERIES
FLANGE LEVER TYPE HYDRAULIC CLAMPING CYLINDER
- HLB-FA 25
- HLB-FA 32
- HLB-FA 40
** PDF DOWNLOAD – HLB-FA SERIES
HYDRAULIC CLAMPING CYLINDER WITH FLANGE TYPE MANIFOLD
- HLB-FAM 25
- HLB-FAM 32
- HLB-FAM 40
** PDF – SERIE HLB-FAM SERIES
HYDRAULIC LEVER CLAMPING CYLINDER WITH MANIFOLD AND FLANGE TYPE FLOW CONTROL
- HLB-FCM 25
- HLB-FCM 32
- HLB-FCM 40
** PDF DOWNLOAD – HLB-FCM SERIES
