CARACTERÍSTICAS ELEMENTOS HIDRÁULICOS
- Inner diameter: ø16~ø40 mm.
- Pmax: 500 Kg/cm².
- This series of hydraulic cylinders is German size, high quality oil seals ensure pressure resistance and standardized specifications are highly interchangeable.
- Axial and side mounting type.
- Choice of single acting and double acting.
- The cylinder body is made of structural carbon steel.
- The surface is specially treated to achieve maximum smoothness of the inner surface and long service life.
SINGLE ACTION
- HBC 16 S 8
- HBC 16 S 20
- HBC 25 S 8
- HBC 25 S 20
- HBC 32 S 10
- HBC 32 S 20
- HBC 40 S 10
- HBC 40 S 20
DOUBLE ACTION
- HBC 16 D 16
- HBC 16 D 50
- HBC 25 D 20
- HBC 25 D 50
- HBC 32 D 25
- HBC 32 D 50
- HBC 40 D 25
- HBC 40 D 50
** PDF® DOWNLOAD – HBC SERIES
HYDRAULIC CYLINDER BLOCKS WITH FRONT MANIFOLD
SHORT STROKE
- HBC-MA 16 D 16
- HBC-MA 25 D 20
- HBC-MA 32 D 25
- HBC-MA 40 D 25
LONG STROKE
- HBC-MA 16 D 50
- HBC-MA 25 D 50
- HBC-MA 32 D 50
- HBC-MA 40 D 50
** PDF® DOWNLOAD – HBC-MA SERIES
HYDRAULIC CYLINDER BLOCKS WITH LOWER MANIFOLD
SHORT STROKE
- HBC-MB 16 D 16
- HBC-MB 25 D 20
- HBC-MB 32 D 25
- HBC-MB 40 D 25
LONG STROKE
- HBC-MB 16 D 50
- HBC-MB 25 D 50
- HBC-MB 32 D 50
- HBC-MB 40 D 50
** PDF® DOWNLOAD – HBC-MB SERIES
SHORT STROKE HYDRAULIC CYLINDER BLOCKS WITH MANIFOLD
SHORT STROKE
- HBC-SM 16 D 16
- HBC-SM 25 D 20
- HBC-SM 32 D 25
- HBC-SM 40 D 25
LONG STROKE
- HBC-SM 16 D 50
- HBC-SM 25 D 50
- HBC-SM 32 D 50
- HBC-SM 40 D 50
** PDF® DOWNLOAD – HBC-SM SERIES
LONG STROKE HYDRAULIC CYLINDER BLOCKS WITH MANIFOLD
SHORT STROKE
- HBC-LM 16 D 16
- HBC-LM 25 D 20
- HBC-LM 32 D 25
- HBC-LM 40 D 25
LONG STROKE
- HBC-LM 16 D 50
- HBC-LM 25 D 50
- HBC-LM 32 D 50
- HBC-LM 40 D 50
** PDF® DOWNLOAD – HBC-LM SERIES
